The climate is under your control
The "Zerten" ZN-I series inverter split system is an effective solution for indoor climate control. The main feature of the device is its principle of operation. When the temperature reaches the setpoint, the split system does not turn off, but continues to operate at a reduced speed. This avoids power surges in the power grid, and reduces the average noise level.
The split system has many modern features that will not only be a pleasant addition, but will be really useful in everyday life. For example, turbo mode, which speeds up the operation of the device for a short period of time, which allows you to quickly cool the room. For night operation, the SLEEP function is provided, when turned on, the device will operate at a lower speed so as not to make unnecessary noise. The built-in timer allows you to set the time to turn on the split system to cool the room before the arrival of the tenants.
During operation, the blinds move up and down to evenly distribute the cooled air throughout the room. If the power was turned off in the house, the split system will automatically resume operation with the settings set before switching off. Environmentally friendly freon R410A is used for cooling, which complies with European standards.
The polypropylene filter guarantees high filtration and protects the internal parts from contamination.
High–performance GREE (LANDA) and Toshiba (GMCC) compressors are a reliable guarantee of efficient operation and safety
Refrigerant R410A – freon with high specific cooling capacity
The removable and washable panel optimizes the operation of the device.
Energy efficiency class A – rational consumption of electricity in all modes
SLEEP function – automatic air temperature control for night sleep
DIMMER function – adjusting the backlight of the indoor unit
The SMART function is an intelligent mode that detects all sources of heat and cold to achieve an optimal indoor climate.
SUPER function – extremely fast heating or cooling
Automatic restart – resuming operation after a power failure in the previous mode
Wide operating temperature range – high performance at low and high outdoor temperatures
24-hour timer – the ability to activate the device's on and off mode for 24 hours without user intervention
| MODEL | ZN-18I | |
| Rated cooling capacity | BTU/hr | 18000 |
| W | 5020 | |
| Rated heating capacity | BTU/hr | 18000 |
| W | 5100 | |
| Energy consumption class (SEER/SCOP) | A | |
| Energy efficiency coefficient for cooling (EER) | 3,21 | |
| Efficiency factor for heating (COP) | 3,62 | |
| Indoor unit noise level | dB (A) | 28 |
| Noise level of the outdoor unit | dB (A) | 52 |
| Power consumption | Cooling, W | 1562 |
| Heating, W | 1410 | |
| Rated current | Cooling, W | 8,12 |
| Heating, A | 8,12 | |
| VENTILATION SYSTEM | ||
| Indoor air circulation | m³/h | 700/600/550 |
| Type of refrigerant | R410A | |
| Volume of refrigerant filling | g | 1205 |
| Additional refrigerant volume | g/m | 10 |
| Operating voltage, frequency, number of phases | V/Hz/F | 220–240/50/1 |
| Compressor type | rotary | |
| Compressor Brand | SANYO | |
| Suction pressure (minimum) | Mpa | 1,9 |
| Discharge pressure | MPa | 4,5 |
| Type of throttling device | capillary tube | |
| Connecting tubes | gas, inch | 3/8 |
| liquid, inch | 1/4 | |
| Maximum length of the copper pipe of the route | m | 10 |
| Maximum height range of the route | m | 5 |
| Maximum room area | m² | 40 |
| Length of the power cord | m | 1,5 |
| Ambient temperature range during cooling | ℃ | от -10 до 43 |
| Ambient temperature range during heating | ℃ | от -10 до 48 |
| Net weight, kg | Indoor unit | 8,5 |
| External unit | 27,8 | |
| Gross weight, kg | Indoor unit | 10,0 |
| External unit | 30,4 |
